Orbit® 接口模块 和 Orbit® 到 PLC 的转换模块

Ethernet/IP 模块
  • Orbit® 数字网络与 Ethernet/IP协议的PLC间的接口模块
  • 通过ODVA测试
  • 轮询及显示数据

PIM模块提供了EtherNet/IP协议PLC和Orbit®协议间的转换接口模块,此模块使得通过EtherNet/IP可以连接多种接触式传感器、非接触式传感器、旋转编码器、温度传感器、压力传感器及开关量传感器等等。 一站式解决方案。 标准的DIN导轨设计,内置的电源可以满足10支传感器使用。通过扩展电源模块,可以连接高达150支传感器。EtherNet/IP协议驱动支持服务器的显示和轮询操作。此接口模块很容易连接到支持EtherNet/IP协议的Rockwell自动化的PLC,其广泛应用于生产、自动化控制及发电和食物加工等领域。

ProfiNet® 与ORBIT®3 接口模块
适应于所有支持ProfiNet协议的PLC的接口模块

PIM接口模块提供了基于ProfiNet协议的可以连接多种接触式、非接触式传感器及旋转编码器、压力传感器的测量网络,一站式测量方案,标准的DIN导轨设计,内置ProfiNet®接口和ORBIT®3 , 可供10根传感器的电源能力。在连接外置电源模块的情况下,可以扩展到150支传感器连接

Ethernet IP Module
PLC Interface: EtherCat™ Module
  • Simple interface between Orbit® and PLC using EtherCat
  • Conformance tested
  • Explicit and Implicit Data



Connecting EtherCat™ PLC to LVDT type sensors is now easy. The EtherCat™ version of the PIM is a PLC compatible EtherCat™ to ORBIT®3 interface module, that enable easy connections between any EtherCat™ enabled controller and Solartron’s flexible ORBIT®3 digital measurement system allowing LVDT type sensors to connect to a PLC..
The PIM makes it simple to interface a wide range of contact and non-contact linear measurement sensors, rotary encoders, temperature and pressure sensors and discrete inputs and outputs via
EtherCat™

This stand alone, Din Rail mounted module provides one port and one ORBIT®3 port which can power up to ten LVDT type displacement sensors or other sensors. This can be extended up to a maximum of 150 sensors with the use of supplementary power modules. The
EtherCat™ protocol driver supports the Explicit and Cyclic Messaging implementation of the protocol as a server. The EtherCat™ port is a very powerful data transfer tool designed for easy connection to EtherCat™ enabled PLCs. Applications are found in many industries including manufacturing, automation and control, power generation and food processing.

Combining multiple sensors using the Orbit Digital Measurement network is easy and data can be read using a Solartron readout or the Gauge Computer Software making system integration simple.

Attention to detail in both design and manufacture of the displacement sensor ensures precision measurement throughout the linear displacement transducer's life.

Solartron Metrology offers a large range of displacement sensors to suit multiple applications with different cable outlets (radial or axial), multiple measuring ranges, different cable types like steel braided which provides additional protection for displacement sensors that are being used in harsh environments. If you cannot find the product you need please contact your local sales office or distributor.



Digital Measurement Orbit Modules and Gateways


Ethernet IP Module
ModbusTCP™ Module
  • Simple interface between Orbit® and PLC using ModbusTCP
  • Conformance tested
  • Cyclic and Implicit Data



Connecting ModbusTCP™ PLC to LVDT type sensors is now easy. The ModbusTCP™ version of the PIM is a PLC compatible ModbusTCP™ to ORBIT®3 interface module, that enable easy connections between any ModbusTCP™ enabled controller and Solartron’s flexible ORBIT®3 digital measurement system allowing LVDT type sensors to connect to a PLC..
The PIM makes it simple to interface a wide range of contact and non-contact linear measurement sensors, rotary encoders, temperature and pressure sensors and discrete inputs and outputs via
ModbusTCP™

This stand alone, Din Rail mounted module provides one port and one ORBIT®3 port which can power up to ten LVDT type displacement sensors or other sensors. This can be extended up to a maximum of 150 sensors with the use of supplementary power modules. The ModbusTCP™ protocol driver supports the Explicit and Cyclic Messaging implementation of the protocol as a server. The ModbusTCP™ port is a very powerful data transfer tool designed for easy connection to ModbusTCP™ enabled PLCs. Applications are found in many industries including manufacturing, automation and control, power generation and food processing.

Combining multiple sensors using the Orbit Digital Measurement network is easy and data can be read using a Solartron readout or the Gauge Computer Software making system integration simple.

Attention to detail in both design and manufacture of the displacement sensor ensures precision measurement throughout the linear displacement transducer's life.

Solartron Metrology offers a large range of displacement sensors to suit multiple applications with different cable outlets (radial or axial), multiple measuring ranges, different cable types like steel braided which provides additional protection for displacement sensors that are being used in harsh environments. If you cannot find the product you need please contact your local sales office or distributor.



Digital Measurement Orbit Modules and Gateways


Orbit® 接口模块 和 Orbit® 到 PLC 的转换模块
  • USB
  • 以太网模块
  • 串口
  • 蓝牙无线接口模块
  • Modbus RTU
  • Profinet
  • Ethernet/IP

不管是台式机, 笔记本电脑 或者 PLC, Solartron 输力强提供了多种接口模块和PLC 网关产品可以直接 通过其连接到Orbit® 测量网络.

接口模块提供了运行Orbit® 指令的控制器和Orbit® 测量模块之间进行通讯的方法,类似于通讯网络 中的网关产品。接口模块负责在控制器和测量网络之间传输和翻译Orbit®指令

Orbit® 第三方接口模块
  • 模拟量输入模块
  • 编码器输入模块
  • 数字量输入/输出模块
  • 数显千分尺接口模块
  • PT100 温度传感器接口模块
  • 应变片式传感器接口模块
  • 力传感器接口模块
  • TTL信号输出模块

输力强不仅仅提供满足尺寸测量的Orbit®数字测量网络,同时可以连接第三方的传感器的接口,大大扩展其应用领域

Air Gauge Module
Air Gauge to Orbit
  • Interfaces to most Air Gauge spindles, mandrels or bore heads
  • High stability Air to Orbit Converter
  • Resolution better than 0.1 µm
  • Pressure 30 psi
  • Simple set up and Mastering using Orbit or integral screen

Solartron Metrology’s Orbit Air Gauge Interface Module (AGM) makes connecting air gauge Measurement Probes to Orbit simple, allowing the user to mix air gauges with all of our contact and non contact sensors to fully utilise the full performance of the Orbit Digital Measurement Network

Combining multiple sensors using the Orbit Digital Measurement network is easy and data can be read using a Solartron readout or the Gauge Computer Software making system integration simple.

Attention to detail in both design and manufacture of the displacement sensor ensures precision measurement throughout the linear displacement transducer's life.

Solartron Metrology offers a large range of displacement sensors to suit multiple applications with different cable outlets (radial or axial), multiple measuring ranges, different cable types like steel braided which provides additional protection for displacement sensors that are being used in harsh environments. If you cannot find the product you need please contact your local sales office or distributor.
Air Gauge to Orbit
